Graph information
| Field | Internal name | Type | Warning | Critical | Info |
|---|---|---|---|---|---|
| Package id 0 | temp1 | gauge | 80.0 | 100.0 | |
| Core 0 | temp2 | gauge | 80.0 | 100.0 | |
| Core 1 | temp3 | gauge | 80.0 | 100.0 | |
| Core 2 | temp4 | gauge | 80.0 | 100.0 | |
| Core 3 | temp5 | gauge | 80.0 | 100.0 | |
| temp1 | temp6 | gauge | |||
| temp1 | temp7 | gauge | |||
| Composite | temp8 | gauge | |||
| temp1 | temp9 | gauge | |||
| temp2 | temp10 | gauge | |||
| temp1 | temp11 | gauge | |||
| temp1 | temp12 | gauge | |||
| temp1 | temp13 | gauge | |||
| Composite | temp14 | gauge |
Zooming is very easy, it's done in 3 clicks (regular clicks, no drag&drop):
- Click to define the start of zoom.
- Click to define the ending of zoom.
- Refresh.
You can use the interactive form too.
